Flexible customized photoelectrochemical cells
Apria


Apria Systems has designed a series of flexible customized electrochemical cells, being possible to select their configuration (gap between electrodes, number of compartments, etc.), the active area and the geometry of the electrodes.
They have a wide variety of electrodes materials (BDD, carbon felt, IrO2, Ni, PtOx, RuO2, stainless steel, Ti, etc.), allowing you to take your cell customization to the next level.
They also offer you maximum flexibility through our interchangeable electrodes and cells, allowing you to test different electrode materials in the same cell or different cells in the same equipment.
Operation mode
Continuous, Recirculation
Configuration
Plate and frame
Max. Operation Pressure
1 bar
Max. Operation Temperature
50 ºC
Max. Operation Current Density
1000 A/m2
Flowrate
Customized
Number of Compartiments
1, 2, 3
Connection type
Barb fitting, Quick plug
Case material
Polypropylene (PP), Stainless steel
Sealing gaskets material
Ethylene propylene diene monomer (EPDM), Thermoplastic polyurethane (TPU), Viton®
Sent directly to Apria
Sent directly to Apria
Optional items
Automatization, Feeding tank, Magnetic stirring, Online measurements (pH, O2 , etc.), Power supply, Pumping, Temperature control
Electrode Type
Frame, mesh, perforated, solid
Electrode Geometry
Circular, Rectangular, Square
Electrodes material
Al, BDD, Carbon felt, IrO2, Ni, PbO2, Pt, PtOx, RuO2, SnO2, Stainless steel, Ti
Electrode Active Surface
Customized up to 300 cm2
Separation between electrodes
Customized up to 2 cm
Volume
Customized
