Max. Potential range (±) / V

10

Voltage resolution (output)

0.003% (30.52 ppm) of range, 300 μV min

Min. Voltage resolution (output) / μV

300

Accuracy voltage (output)

0.1% of setpoint, 2 mV min

Min. Accuracy voltage (output) / mV

2

Compliance voltage / ±V

12

Voltage resolution (input)

0.003% (30.52 ppm) of range, 300 μV min

Min. Voltage resolution (input) / μV

300

Accuracy voltage (input)

0.1% of measured, 1 mV min

Min. Accuracy voltage (input) / mV

1

Voltage Ranges

1 range, [±10 V]

Number of Voltage Ranges

1

Slew rate

5 kV/s (-1 V to +1V) - (1 kΩ load)

Min/Max Scan Rate

300 μV/s minimum & 25 V/s maximum with 10 mV sampling

Smallest Potential Step for Sweep Voltammetry

0.003% (30.52 ppm) of range, 300 μV min

Smallest Pulse Width

375 μs

Square Wave Voltammetry Max Frequency

1 kHz (-1 V to +1V)

Time Resolution

10 ns

iR Compensation Limits

1.82 V max

Required Compliance Voltage

≥ 10 V, ≥ 5 V, ≥ 2 V

Max. current (output) / A

±100 mA

Current range

8 ranges, [10 nA to 100 mA]

Number of current ranges

8

Current Resolution (output)

0.003% (30.52 ppm) of range, 300 fA min

Min. Current Resolution (output) / pA

0.3

Current Accuracy (output)

0.1% of range, 1 nA min

Min. Current Accuracy (output) / nA

1

Current Resolution (input)

0.003% (30.52 ppm) of range, 300 fA min

Min. Current Resolution (input) / pA

0.3

Current Accuracy (input)

0.1% of range, 1 nA min

Min. Current Accuracy (input) / nA

1

EIS Capability

No
