PguEducation
IPS Elektroniklabor
Specifications
General
Type
Potentiostat/Galvanostat
Dimensions - WxDxH / cm
24.7 x 32.6 x 41.8
Weight
3.95 kg
PC Interface
USB
Power supply
90 – 264 VAC, 47/63Hz
General Potentiostat
Form Factor
Benchtop / Lab
Channels
≥ 1
Cell connection
4 electrode, 3 electrode
ADC resolution
16 bit
Ambient temperature when measuring
-10 °C to +105 °C
Channel Cable Length
On demand
Input impedance
> 1 TΩ (//20 pF)
Potentiostat rise/fall time
< 2 µs
Acquisition time
>100 µs
Analog I/O
Yes, 1
Floating option
Yes
Analog filters
from 1 µs to 1 s
Digital filters
Yes
Potentiostatic
Max. Potential range (±) / V
5
Voltage resolution (output)
0.003 % FSR, Best: 30 µV
Min. Voltage resolution (output) / μV
30
Accuracy voltage (output)
< 0.1 % FSR (Full Scale Range)
Compliance voltage / ±V
17.5
Voltage Ranges
±1 V, ±2 V and ±5 V
Number of Voltage Ranges
3
Min/Max Scan Rate
Maximum scan rate 200 V/s
Potential Range Required (±) / V
±1 V or higher, ±4 V or higher
Required Compliance Voltage
≥ 15 V, ≥ 10 V, ≥ 5 V, ≥ 2 V
Galvanostatic
Max. current (output) / A
±100 mA
Current range
9 ranges, ±1 nA to ±100 mA, 12 ranges with low current probe, ±1 pA to ±100 mA (with low current probe)
Number of current ranges
9
Current Resolution (output)
0.003 % FSR Best: 30 fA
Min. Current Resolution (output) / pA
0.03
Current Accuracy (output)
< 0.1 % FSR (Full Scale Range)
Max. Current
≥ 100 mA, ≥ 1 mA
Impedance
EIS Capability
Yes
EIS frequency range
10 µHz to 1 kHz, 10 µHz to 5 MHz if connected to the OGFEIS
Min. EIS frequency range / µHz
10
Max. EIS frequency range / MHz
0.001, 5
Max. EIS Frequency range
≥ 1 kHz
Min. EIS Frequency range
≤ 100 Hz, ≤ 10 Hz, 10 mHz
