Metal-ion 4-point EIS, model A – Metal-ion 4-point Electrochemical Impedance Spectroscopy Cell, model A
Redoxme
CompreCell DP
Price: On Request
Description
Superior hardware and software tools for mastering electrochemical research and experiments
Since 2013, we have been combining electrochemistry and engineering know-how with a passion for innovation to deliver high-value laboratory equipment and software. Our goal is to accelerate and standardize research in the energy storage and conversion field. We follow a customer-centric approach: We take the time to understand your requirements and problems in detail and to find the best solutions together with you.
Specifications
General
Applications
Solid-state battery, Solid electrolyte
Storage conditions
Storage +10 to +40 °C, Drying up to +100 °C, RH 0–80% (non-condensing), Non-corrosive atmosphere, Storage +10 to +40 °C
Dimensions
6cm x 6 cm x 13.4 cm
Weight
~1.3 kg
Operating temperature
-40 °C up to +250 °C, Tmax depends on selected sleeve material
Battery testing
Max Battery Thickness
10 mm
Piston diameter
6 mm, 12 mm, 10 mm
Piston material
Hard metal (90% WC / 10% Co)
Max. Applied voltage
40 V (AC/DC)
O-ring material
FFKM
Max. Pressure
1.7 GPa (6 mm diam. piston), 955 MPa (10 mm diam. piston), 663 MPa (12 mm diam. piston)
Sleeve material
PEI, PEEK, Al₂O₃
Airthight
Helium-leakage tested
Compression architecture
Dual piston, can opened from both sides
Product type (battery)
Solid-electrolyte test cell, Solid-state battery test cell
Max. Applicable force
50 kN (6 mm diam. piston), 75 kN (10 mm and 12 mm diam. piston)
General Cells
Electrode configuration
2-electrode, 3-electrode
