MedPstat 2.0 (Advance)

Name: MedPstat 2.0 (Advance)
Brand: MTX Labs
Price: 2999 USD

See all products by MTX Labs

Price: 2,999.00 USD

Description

MedPstat 2.0 Advance is a Portable, Affordable, & Precision Potentiostat/Galvanostat with a wide range of ± 10V, 250 mA. Optimum for electrochemistry research applications. Included is a high-quality dummy cell for learning & calibration applications and lifetime access to free software - MedEplot for PC, data acquisition & plotting.

Specifications

General

Type

Potentiostat/Galvanostat

Dimensions - WxDxH / cm

9.15 x 18.1 x 4.2

Weight

0.320 kg

PC Interface

USB

Power supply

100 – 240 VAC, 50/60Hz

General Potentiostat

Form Factor

Portable

Channels

≥ 1

Cell connection

4 electrode, 3 electrode

ADC resolution

16 bit

Ambient temperature when measuring

0 °C to +50 °C

Channel Cable Length

0.8 m

Input impedance

>10 TΩ

Input Bias Current

1 pA Max

Bandwidth

Up to 4 MHz

Max. data acquisition rate

1 KHz

Potentiostatic

Max. Potential range (±) / V

Voltage resolution (output)

152 µV

Min. Voltage resolution (output) / μV

152

Accuracy voltage (output)

0.1% of the setpoint, 1mV Max

Min. Accuracy voltage (output) / mV

Compliance voltage / ±V

Voltage resolution (input)

156 µV

Min. Voltage resolution (input) / μV

156

Accuracy voltage (input)

0.1% of the setpoint, 1mV Max

Min. Accuracy voltage (input) / mV

Slew rate

45V/µs (No Load)

Potential Range Required (±) / V

±1 V or higher, ±4 V or higher, ±10 V or higher

Required Compliance Voltage

≥ 15 V, ≥ 10 V, ≥ 5 V, ≥ 2 V

Galvanostatic

Current range

7 Ranges (100nA to 250mA)

Number of current ranges

Current Resolution (output)

1.52 nA

Min. Current Resolution (output) / pA

1520

Current Resolution (input)

0.015% of range, 1.5 pA

Min. Current Resolution (input) / pA

1.5

Current Accuracy (input)

0.5% of the range, 50pA max

Min. Current Accuracy (input) / nA

0.05

Max. current (output) / A

±250 mA

Max. Current

≥ 250 mA, ≥ 100 mA, ≥ 1 mA

Impedance

EIS Capability
